Tracked Outrigger Scissor Lift Platform

Product

Description

The SWPT0407TL-Tracked Outrigger Scissor Lift Platform, meticulously crafted by swllift, is an aerial work platform designed for complex terrain and diverse working conditions. The machine combines a tracked chassis with outrigger support structures, ensuring excellent mobility while enhancing operational stability. It can flexibly adapt to various aerial work environments, including outdoor construction, equipment installation, and on-site maintenance.

In terms of performance configuration, this model adopts a new energy drive system and a high-efficiency AC motor, featuring energy saving, environmental friendliness, powerful performance, and stable operation. Coupled with an intelligent human-machine interface system, it enables fault diagnosis, parameter management, and operational monitoring. Furthermore, features such as automatic leveling outriggers, emergency stop, tilt protection, and multiple safety linkage designs provide a safer and more reliable operating environment for aerial work.

Product

Features

Flexible Access and Convenient Transportation

The SWPT0407TL tracked outrigger scissor lift aerial work platform boasts excellent terrain adaptability and mobility, easily handling complex working environments. Its compact structure facilitates vehicle transport and on-site transfer, enhancing its maneuverability under various working conditions.

Intelligent Control and System Integration

The equipment integrates a human-machine interface and intelligent management system, supporting fault diagnosis, parameter reading and writing, and overall machine operation monitoring, making operation more intuitive and efficient. Through systematic control, users can monitor equipment status in real time, improving usage and maintenance efficiency.

High-Efficiency Power and Environmentally Friendly Drive

Utilizing a new energy power system, the machine is characterized by its small size, light weight, and pollution-free operation. Equipped with a high-efficiency AC motor, it delivers strong torque and stable, reliable operation, improving work efficiency while also ensuring energy conservation and environmental protection.

Safety Support and Multiple Protections

The SWPT0407TL is equipped with a one-button automatic leveling outrigger system, quickly achieving stable platform support and enhancing operational safety. It integrates a platform with self-locking doors, automatic braking, emergency stop and emergency descent systems, and combines tilt protection and fault diagnosis functions to provide comprehensive safety protection for high-altitude operations.

Application

Scenarios

Warning: array_chunk() expects parameter 1 to be array, bool given in /www/wwwroot/swllift.com/wp-content/themes/swlift/single-equipment.php on line 295

Warning: Invalid argument supplied for foreach() in /www/wwwroot/swllift.com/wp-content/themes/swlift/single-equipment.php on line 296

product

Parameter

Model number		SWPT0407TL Motor drive
Max.working height	M	6
Platform size	M	1.4×0.76
Platform extension dimension	M	0.6
Machine height (Guardrial raised)	M	1.95
Machine height (Guardrial folded)	M	1.56
Whole length	M	2.01
Whole width	M	0.88
Rated load	Kg	230
Drving speed (folded mode)	km/h	2.5
Max.climbing capacity	%	30
Wheel size	mm	180/72/42
Storage battery	/	2×12V/120Ah
Whole weight	Kg	1095
Track legs	/	one-button leveling
