Wheeled Electric Scissor Lift Platform

Produkt

Popis

The SWGTJZ0406X wheeled electric scissor lift is a compact aerial work platform designed for various indoor and outdoor applications. The entire machine utilizes an electric drive system, ensuring smooth operation, low noise, and environmental friendliness. Combined with proportional control technology, it achieves precise and smooth lifting and movement, significantly improving work efficiency. It is suitable for various working conditions, including warehousing and logistics, equipment maintenance, and installation.

In terms of safety and practicality, the SWGTJZ0406X is equipped with a comprehensive safety protection system, such as automatic pothole protection, emergency stop, and emergency descent devices, effectively ensuring safety during operations. Meanwhile, the extended platform and folding guardrail design enhance working space and flexibility. Combined with durable solid non-marking tires and multiple auxiliary configurations, the equipment maintains stable and reliable performance in different environments.

Produkt

Vlastnosti

Comprehensive Safety Upgrades

The SWGTJZ0406X is equipped with multiple safety systems, including an automatic pothole protection system, platform self-locking doors, an automatic braking system, an emergency stop button, and an emergency descent system, effectively responding to emergencies. Combined with tilt alarms, explosion-proof piping systems, and safety support designs, it comprehensively ensures the safety of personnel and equipment working at height, improving operational reliability.

Stable and Efficient Operation

The equipment employs proportional control technology, achieving smooth and precise lifting and movement operations. Coupled with an onboard diagnostic system and hourly meter function, users can easily monitor the equipment's status and usage in real time, improving work efficiency and reducing maintenance difficulty.

Flexible and Practical Structural Design

This platform features an extended platform and folding guardrail design, expanding the working space while ensuring convenient transportation and storage. Furthermore, the forklift slot design facilitates loading, unloading, and transfer, and the overall structure is more suitable for various construction scenarios.

Optimized Mobility and Auxiliary Configurations

The SWGTJZ0406X features solid, non-marking, silent tires, suitable for various indoor and outdoor ground environments. It is also equipped with a mobile alarm horn, flashing lights, and other warning devices to enhance visibility and safety during operation. The charger protection function further extends the equipment's lifespan and enhances overall stability.

Aplikácia

Scenáre

Warning: array_chunk() expects parameter 1 to be array, bool given in /www/wwwroot/swllift.com/wp-content/themes/swlift/single-equipment.php on line 295

Warning: Invalid argument supplied for foreach() in /www/wwwroot/swllift.com/wp-content/themes/swlift/single-equipment.php on line 296

produkt

Parameter

Model	SWGTJZ0406X
Max. Pracovná výška	5,8 m
Max. Výška platformy	3,8 m
Maximálna nosnosť	230 kg
Zdvíhacia kapacita – vysunutá predlžovacia plošina	113 kg
Working Platform Dimensions（L*W）	1300 mm × 680 mm
Overall dimensions of the machine (L×W×H,unfolded guardrail)	1440 mm × 700 mm × 1860 mm
Overall dimensions of the machine (L×W×H,folding guardrails)	1440 mm × 700 mm × 1460 mm
Výsuvná predĺžená plošina – dĺžka	550 mm
Minimálna svetlá výška	106 mm/29 mm
Rázvor kolies	1020 mm
Turning radius -inside/outside	0/1,5 m
Zdvíhací/pohonný motor	1,6 kW/0,5 kW
Rýchlosť zdvíhania	3-5m/min
Drive speed-stowed	3,5 km/h
Drive speed-raised	0,8 km/h
Batéria	2*12V 80AH
Nabíjačka	24V/30A
Max.climbing ability	20%
Max. Pracovný anjel	1,5°/3°
Pneumatiky	Φ230×80 mm
Celková váha	860 kg
